Controllers

  Nominal input voltage 24 V
- Maximum operating voltage 30 V
- Overvoltage point 33 V
- Minimum operating voltage 16 V (= undervoltage point)
- Electrical isolation to heatsink 500 V ac (minimum)
- PWM operating frequency 15 kHz
- Controller Weight: 1.1 kg (2.5 lbs)
- Controller Dimensions: 122 × 165 × 66 mm (4.8" × 6.5" × 2.6")
