3.0T LPG forklift
3.0T LPG forklift

LPG forklift

3.0T LPG forklift



Model 3.0T LPG forklift
GTFL30Y-B GTFL30Y-K
Power
1 Engine Model   GQ4Y-491 Nissan K25
2 Rated Power kw/r.p.m 34.2/2600 54/2800
3 Rated Torque Nm/r.p.m 142/1800 202/1800
4 Bore×Stroke mm 89X100 93x102
5 Cylinder Amount   4 4
6 Displacement L 2.065 2.771
7 Gears   1/1 Power Shift 1/1 Power Shift
8 Working Pressure Mpa 17.5 17.5
9 Battery Voltage V/Ah 12/90 12/90
Features
10 Rated Load kg 3000 3000
11 Lifting Height mm 3000 3000
12 Free Lifting Height mm 145 145
13 Load Center mm 500 500
14 Fork Size Long×Wide×Thick mm 1070x125x45 1070x125x45
15 Mast Dip Angle Front/Rear 6/12 6/12
16 Minimum Turning Radius mm 2400 2400
17 Minimum Ground Clearance mm 120 120
18 Front Overhang mm 475 475
Performance
19 Max.Travelling Speed Full load km/h 20 20
20 Max. Lifting Speed Full load/without loading mm/s 470/520 470/520
21 Max. Traction Full load KW 18 18
22 Max. Gradeability % 20 20
23 Max. Fork Lifting height With Load Backrest mm 4265 4265
Dimension
24 Overall Length Without Fork mm 2695 2695
25 Overall Width mm 1230 1230
26 Overhead Guard Height mm 2090 2090
27 Mast landing height mm 2055 2055
Chassis
28 Tire Front   28x9-15-12PR 28x9-15-12PR
29 Rear   6.50-10-10PR 6.50-10-10PR
30 Wheel Base mm 1700 1700
31 Wheel Tread Front/Rear mm 1000/970 1000/970
32 Fuel Tank Volume L 70 70
Curb Weight
33 Curb Weight No-load Kg 4350 4350

 Safe & Efficient
·Handle cut-power brake function makes it able to park on ramps while preventing slide. Equipped with
  emergency reversing device and it is safe and highly efficient;
·5 pivots structure makes it running safely;
·Open visibility makes it safe to operate.

Flexible Control
·Equipped with Curtis control system,features in CVT and impeccable protection function.

Stable & Reliable
·Vertical typed drive unit gives smaller turning radius, easier driving wheel replacement,
  continent  maintenance. Motor is better in dust and water proof, extended life cycle of brake and motor;
·High elastic polyurethane wheel with long service life equipped;
·CURTIS multifunctional combined instruments equipped;
·Swiss BUCHER hydro power unit equipped, providing energy conservation and noise reduction and
   stable operation;
·High power capacity battery gives long lasting power and traction.
