AWP10-1200
AWP10-1200

Platform Height 10000
Work Height 11700
Payload 125
Power AC/DC

AWP10-1200

 Specification TILTING ALUMINIUM ALLOY LIFTING PLORM
AWP6-1200 AWP8-1200 AWP10-1200
Max.Platform Height(mm) 6000 8000 10000
Working Height(mm) 7700 9700 11700
Ground Clearance(mm) 80
Lift Rated Capacity(kg) 150 125 125
Platform Size(mm)              650*600
Outspread Size(mm) 1930*1770
Electrical Source AC(v) 220
DC (v) 24
Battery v/Ah 2*12/60
Charger v/A 24/10
Lifting Moter AC v/kw 220/0.75
DC v/kw 24/2.0
Overall Length(mm) 1580
Overall Width(mm) 800
Overall Heith(mm) 1950 2050 2150
Overall Net Weight AC(kg) 300 350 400
DC(kg) 330 380 430

The Tilting Aluminium Alloy Lifting platform  has the following characteristics:

1.Lift or fall steadily: The seamless transmission is used between the lifting masts, thus minimizing the amount of sway after lifting.

2.Safe and reliable: The four turning stabilizers of the unit connected to the four corners of the chassis support the MEWP duringwork. They are designed for leveling regulation and preventing inclination. They are composed of stand bars and turning legs. The stand bars are installed in the turning legs. Extending out the turning legs before operating the unit enlarges the area of supporting. Therefore, the steadiness of the whole platform is guaranteed.

3.Convenient: The whole work platform is light because the lifting masts are made of alloy aluminum. The structure is compact and the volume is small, so only one person can move the equipment and carry it through a very narrow passage.
